Trek Supercaliber 9.9 XTR
Details
Supercaliber 9.9 is the fastest, lightest, and most capable cross country race bike we make—and that's exactly why it's Trek Factory Racing's World Cup bike of choice. The exclusive IsoStrut integrated shock is the cornerstone of Supercaliber's efficient suspension system, giving you a fast and light ride that charges through rugged terrain at breakneck speed. The high-end mountain bike parts spec comes dripping with carbon, and includes the highest-performance drivetrain, brakes, and wheels you can get.
It's right for you if...
You're gunning for the top spot and looking for a pro-level cross country race bike that has top-of-the-line everything. You want a bike that comes spec'd with the best parts and suspension available-plus tons of carbon-for knock-out, drag-out speed and capability.
The tech you get
An ultra-lightweight, full OCLV Mountain Carbon frame with 60mm of travel, a 100mm Fox Factory 32 Step-Cast fork with FIT4 damper, and Trek's exclusive IsoStrut FOX Factory shock designed specifically for Supercaliber. Plus, dual remote suspension lockout, a Shimano XTR drivetrain with E*thirteen carbon cranks, Bontrager Kovee XXX 30 OCLV Mountain Carbon wheels with a 54-tooth DT Swiss rear hub for fast engagement, Shimano XTR brakes, a Bontrager XXX OCLV carbon seatpost, and Bontrager Kovee XXX OCLV carbon handlebar.
The final word
If you don't podium, sorry, but you can't blame it on this bike. Its insanely light carbon frame is spec'd for the pros using the most advanced MTB components out there, including our cutting-edge IsoStrut integrated shock. Saddle up and see what you're made of.
Why you'll love it
- Supercaliber 9.9 is the ultimate XC race bike, one you'll see taking top spots during the World Cup
- Our exclusive IsoStrut shock provides tuneable, damped suspension for a smooth and efficient ride
- Pivotless seat stays save on weight and actively bend to help soak up trail chatter
- Wider Kovee XXX 30 wheels provide better tire support so you can run lower pressure and get more traction
Specs
| Frame | OCLV Mountain Carbon main frame & stays, IsoStrut, tapered head tube, Knock Block, Control Freak internal routing, Boost148, 60mm travel |
|---|---|
| Fork | Fox Factory 32 Step-Cast, Float EVOL air spring, FIT4 2-position damper, dual remote, tapered steerer, 44mm offset, Kashima Coat, Boost110, 15mm bolt-on axle, 100mm travel |
| Headset | Knock Block Integrated, super light sealed cartridge bearing, 1-1/8" top, 1.5" bottom |
| Rear Shock | Trek IsoStrut, Fox Factory shock, air spring, DPS 2-position remote damper, Kashima Coat, 235 x 32.5mm |
| Rims/Wheels | Bontrager Kovee XXX 30, OCLV Mountain Carbon, Tubeless Ready, centerlock, Boost110 front, Boost148 rear |
| Tires | Bontrager XR1 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29" x 2.20" |
| Crankset | Shimano XTR 9120 34T |
| Chainrings | 34T |
| Bottom Bracket | Shimano XTR PF92 |
| Chain | Shimano XTR M9100, 12 speed |
| Rear Derailleur | Shimano XTR M9100, Shadow Plus, long cage, 51T max cog |
| Cassette/Rear Cogs | Shimano XTR M9100, 10-51, 12 speed |
| Shifters | Shimano XTR M9100, 12 speed |
| Handlebars | Bontrager Kovee XXX, OCLV Carbon, 35mm, 0mm rise |
| Tape/Grips | ESI Chunky |
| Stem | Bontrager Kovee Pro, 35mm, Knock Block, Blendr compatible, 0 degree |
| Brakes | Shimano XTR M9100 hydraulic disc |
| Saddle | Bontrager Montrose Pro, 7x10mm carbon rails, 138mm width |
| Seat Post | Bontrager XXX, OCLV Carbon, 31.6mm, 0mm offset |
* Subject to change without notice.
Videos
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Matte Carbon/Gloss Black / Small | 601842222959 | 595437 | |
| Matte Carbon/Gloss Black / Medium | 601842222942 | 595438 | |
| Matte Carbon/Gloss Black / Medium/Large | 601842222935 | 595439 | SUP4065830K |
| Matte Carbon/Gloss Black / Large | 601842222928 | 595440 | |
| Matte Carbon/Gloss Black / X-Large | 601842222911 | 595441 | |
| Viper Red / Small | 601842222836 | 595449 | |
| Viper Red / Medium | 601842222829 | 595450 | |
| Viper Red / Medium/Large | 601842222812 | 595451 | |
| Viper Red / Large | 601842222805 | 595452 | |
| Viper Red / X-Large | 601842222799 | 595453 | |
| Miami Green to Volt Fade / Small | 601842222898 | 595443 | |
| Miami Green to Volt Fade / Medium | 601842222881 | 595444 | |
| Miami Green to Volt Fade / Medium/Large | 601842222874 | 595445 | |
| Miami Green to Volt Fade / Large | 601842222867 | 595446 | |
| Miami Green to Volt Fade / X-Large | 601842222850 | 595447 |
