Giant Cypress 3
$630.00
Details
Comfort, control, a breeze to ride. With an adjustable stem, suspension seatpost and grippy tires, Cypress makes it easy to experience the simple joy of riding a bike.
With its lightweight yet durable ALUXX aluminum frame, upright positioning, and smooth-rolling 700c wheels, Cypress is an easy rider on all types of roads and paths.
| Size | Small | Medium | Large | X-Large |
|---|---|---|---|---|
| A SEAT TUBE LENGTH (mm) | 385 | 435 | 485 | 535 |
| B SEAT TUBE ANGLE | 73.0° | 73.0° | 72.5° | 72.5° |
| C TOP TUBE LENGTH (mm) | 570 | 585 | 600 | 615 |
| D HEAD TUBE LENGTH (mm) | 130 | 145 | 160 | 175 |
| E HEAD TUBE ANGLE | 70.5° | 70.5° | 70.5° | 70.5° |
| F FORK RAKE (mm) | 42 | 42 | 42 | 42 |
| G TRAIL (mm) | 83.6 | 83.8 | 83.8 | 83.8 |
| H WHEELBASE (mm) | 1089 | 1105 | 1121 | 1137 |
| I CHAIN STAY LENGTH (mm) | 465 | 465 | 465 | 465 |
| J BOTTOM BRACKET DROP (mm) | 65 | 65 | 65 | 65 |
| K STACK (mm) | 617 | 631 | 645 | 659 |
| L REACH (mm) | 381 | 392 | 397 | 407 |
| N HANDLEBAR WIDTH (mm) | 640 | 680 | 680 | 680 |
| O STEM LENGTH (mm) | 80 | 80 | 90 | 90 |
| P CRANK LENGTH (mm) | 170 | 175 | 175 | 175 |
| Q WHEEL SIZE | 700C | 700C | 700C | 700C |
| Size | Rider Height |
|---|---|
| Small | 160 cm to 170 cm |
| Medium | 170 cm to 180 cm |
| Large | 180 cm to 190 cm |
| X-Large | 190 cm to 200 cm |
Due to supply-chain issues, Specs are subject to change without notice.
Specs
| Frame | ALUXX-Grade Aluminum |
|---|---|
| Fork | high-tensile steel, rack mount |
| Rims | Giant double-wall aluminum |
| Hubs | alloy, 32h |
| Spokes | stainless, 14g |
| Tires | Innova Multi Purpose Hybrid, 700x45c |
| Bottom Bracket | sealed cartridge |
| Crankset | forged alloy, 38t S:170mm, M:170mm, L:175mm, XL:175mm |
| Shifters | microSHIFT Acolyte, 1x8 |
| Rear Derailleur | microSHIFT Acolyte |
| Cassette/Freewheel | microSHIFT Acolyte, 12x42 |
| Chain | KMC Z8.3 |
| Brakes | Tektro mechanical [F]160mm, [R]160mm rotors |
| Brake Levers | alloy |
| Handlebars | alloy, mid-rise, 25.4mm S:64cm, M:64cm, L:68cm, XL:68cm |
| Tape/Grips | Giant Ergo |
| Stem | alloy, quill, 40-degree, 25.4mm S:85mm, M:85m, L:105mm, XL:105mm |
| Seatpost | Giant Sport, 30.9mm S:300mm, M:300mm, L:350mm, XL:350mm |
| Saddle | Selle Royal Vivo Comfort |
| Pedals | fitness platform |
| Accessories & Extras | 55mm max tire size |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Knight Shield / Small | 04712878767416 | 2200161124 | CYP21285812D |
| Knight Shield / Medium | 04712878767423 | 2200161125 | CYP21404916D |
| Knight Shield / Large | 04712878767430 | 2200161127 | CYP21328323D |
| Knight Shield / X-Large | 04712878767447 | 2200161128 | CYP22419632D |
| Phantom Green / Small | 04712878767461 | 2200161224 | CYP21292256N |
| Phantom Green / Medium | 04712878767478 | 2200161225 | CYP21914882N |
| Phantom Green / Large | 04712878767485 | 2200161227 | CYP21461842N |
| Phantom Green / X-Large | 04712878767492 | 2200161228 | CYP22955268N |
